United States Patent <Patent No: US7,918,584> Date of Patent: Apr.5.2011
JAPAN Patent <Patent No: 5173231> Date of Patent: Jan.11.2013




[Dot image] Floating Ball Description

Full video data capability with 360°viewing angle

Each LED “.image” cube is independent, and has 360-degree viewing angle.
With full color depth (8bit per R, G, B), 1 unit represents 1 pixel of movie data. You can produce large 3D motion images by linking multiple units that the audience can view in halls.

Lightweight units provide high speed movement of free form images
The LED “.image” cubes are suspended from trusses above the stage. The motors drive them vertically providing movement to the 3D images. Units are lightweight (about 200g per cube) and the high speed movement capability (5m/s), provide you with the ability easily program the motion of complex objects. For example, the rippling of a water surface, the beating of a birds' wings, the morphing of geometric forms, and more.

9 Nichia full color LEDs per unit
Nichia lamp, 9 full color LEDs are mounted on 1 unit. They provide effective brightness and full illumination.

DMX512 & CAN control
Each unit has 1 DMX512 input and 6 attributes, Red − Green − Blue − Height (Course) − Height (Fine) − Reset. Daisy chain connection is also available. If the units are daisy chained communications between the units are processed using the CAN (Controller Area Network) protocol. This is the same protocol used to control in-vehicle units of automobiles. Since CAN communication will be applied from a second unit, you just need to send the DMX512 signal to first unit. CAN control provides for high-speed and low-noise communication.

Control via 3D CG applications or “ArKaos VJ 3.6.1 DMX” & “LED Mapper”
You can control the 6 attributes of each unit via the popular 3D CG applications. By installing a dedicated plug-in, the color and height data of each pixel simulated in the 3D CG application will be converted to the DMX protocol and sent directly from your computer to “.image”.
Alternatively, “ArKaos LED Mapper” is also usable. ArKaos LED Mapper can send the video output played with “ArKaos VJ 3.6.1 DMX” through the Ethernet port of a computer in the Art-Net protocol. The video output signal (VGA or DVI) will be converted to a DMX (Art-Net) signal in real-time without the need for using expensive hardware to convert a video signal into a DMX signal.
By setting the video (color) data with the ArKaos LED Mapper, and merging it with the height data set in the other console, you can produce 3D smooth moving objects with “.image”. In addition, movie data in DVDs or video tapes can easily be projected to “.image” easily using the ArKaos VJ DMX & LED Mapper.


Specifications

Item Conditions 450
Drive Unit Control USSIT DMX 512 - 3 channels (Height-Course, Height-Fine, Reset) (CAN control in daisy-chained network.)
Maximum Up / Down Transfer Speed 1.5m/sec
LED Configuration: Nichia full color LED x 12
LED Unit Control / Viewing Angle 360° USSIT DMX 512 - 3 channels (Red, Green, Blue)
Minimum Dot Pitch 150mm
Power Consumption AC100V/0.5A
Dimensions Drive part: Width 150mm Depth 150mm Height 370mm,
LED unit: Width 50mm Depth 50mm Height 50mm
Weight 3kg (LED unit: 30g)
Source Compatibility Simulated data of 3D CG applications 、
Environmental Temperature : -10℃to 40℃
Requirements Humidity : 0% to 70%
Patent

United States Patent<Patent No: US7,918,584> Date of Patent: Apr.5.2011
JAPAN Patent <Patent No: 5173231> Date of Patent: Jan.11.2013
